The Folding Party Tray
LIST OF MATERIALS
(finished dimensions in inches - all made from 1/2" plywood)
|
A
|
Legs (4) | 3/4 x 2-1/8 x 28 |
|
B
|
Lower Brace (1) | 3/4 x 2-1/8 x 22-1/2 |
|
C
|
Spacer (2) | 3/4 x 1" outside diameter |
|
D
|
Upper Brace (1) | 3/4 x 2-1/8 x 19-1/2 |
|
E
|
Dowel Brace (1) | 3/4 dowel - 19-1/2 long |
|
F
|
Brace Lock (2) | 3/4 x 2-1/8 x 3-13/16 |
|
G
|
Skirt (2) | 3/4 x 2-1/8 x 15-5/8 |
|
H
|
Top (4) | 3/4 x 3-13/16 x 24 |
| HARDWARE | ||
|
(2)
|
1/4 "-20 x 1-1/2" carriage bolts | |
|
(2)
|
1/4 "-20 x 2-1/4" carriage bolts | |
|
(4)
|
1/4 "I.D. flat washers | |
|
(4)
|
1/4 "-20 locking cap nuts | |
|
(26)
|
#8 x 2" roundhead wood screws | |
|
(28)
|
#8 I.D. flat washers | |
|
(2)
|
#8 x 1" flathead wood screws | |
|
(8)
|
#8 x 1-1/2" flathead wood screws | |
View
Plans &
Assembly Drawings
Side
View
Leg & Space Layout
Brace End Layout
Brace Lock & Spacer
Skirt Layout
Inner Leg Layout
Outer Leg Layout
Assembly
List of Materials
Printer Friendly PDF copy of Instructions
